Corn Starch Making Machinery Flash Dryer 380v 50hz Stainless Steel304

Minimum Order Quantity : 1set Price : 2000-999999USD
Packaging Details : nude packing Delivery Time : 30days
Payment Terms : L/C, T/T
Place of Origin: china Brand Name: ZY
Model Number: FS

Detail Information

Material: Stainless Steel304 Capacity: 6 Ton/h
Warranty: 1year Voltage: 380v50hz
Color: Silvery White Height: 12m
Function: Starch Drying Machine Name: Flash Dryer
High Light:

corn hammer mill

,

spin flash dryer

Product Description



Low Power Consumption Corn Starch Processing Machinery /Starch Flash Dryer



Feature of flash dryer :

  • There is special cooling device at the bottom of dryer, it can avoid the material deteriorate in the bottom high temperature area.
  • Special air sealing device and bearing cooling device and make the life of transmission device longer effectively.
  • There is special air distributing device, it reduces the resistance of equipment, and make the air speed in drying chamber be balanced.
  • There are classification rings and turbojet plates in the drying chamber, fineness and final moisture of product and be adjusted and controlled.
  • In the drying chamber air speed is fast, drying time is short, it can avoid material stick on the wall and deterioration effectively.





Type of flash dryer :



Type Capacity Material
VF-2 2t/h dry starch SS304
VF-4 4t/h dry starch SS304
VF-6 6t/h dry starch SS304
VF-8 8t/h dry starch SS304
VF10 10t/h dry starch SS304










Working Principle:



The flash dryer consists of dry main engine, feeder, heat source device (hot air furnace or steam), air filter, air blower,

cyclone separator, bag filter, and induced draft fan. The hot air tangentially enters the bottom of the dryer and is driven by the agitator to form a powerful rotating wind field. The paste material enters the dryer by the screw feeder. Under the strong action of the high-speed rotating stirring paddle, the material is dispersed under the action of impact, friction and shearing force, the block material is rapidly pulverized, and it is fully contacted with hot air and heated ,and dry. The dehydrated dry material rises with the hot gas flow, and the classification ring intercepts the large particles. The small particles are discharged from the center of the ring to the outside of the dryer, and are recovered by the cyclone separator and the dust collector. The dry material is not dried or the bulk material is subjected to centrifugal force , fell to the bottom and was crushed and dried.







FAQ:





Q1: Is your company a factory or trading company?

A: Our company is a factory in Henan Province ,with export license

and we have done export business over 20 years professionally.

Q2. What is your main business?

A: ZY is devoted to starch processing machine. The machine of starch processing line , such as : cassava starch line , cassava flour line , potato starch line , sweet potato line , wheat starch ,sago line and garri line

Q3: Where is your factory located? How can I visit there?

A: Our add: Jianshe Road , Zhengzhou City , Henan Province , China.

Warmly welcome to visit us!

Q4: Are your products can be assured ?

A: Our machines are all passed ISO9001:2001 and have CE certificate by SGS, TUV.
